FIONA: Innovative Network Appliance for Big Data

RCI Networking and Expertise Make FIONA a Star for Collaborative Success

May 23, 2014

The good news is that with the Prism@UCSD NSF grant, your lab can have a dedicated optical fiber network connection 1000x faster than the shared Internet. The bad news is, now you have 1000x as much data pouring into your lab every second as you had before. This challenge has led to an innovative solution—a "Big Data" networked PC appliance called FIONA, which has been carefully engineered to handle these huge data flows.

"FIONA was designed to resolve the real network problem for big data." — Dr. Phil Papadopoulos, PI of the Prism@UCSD grant

The Flash I/O Network Appliance (FIONA), designed by Drs. Phil Papadopoulos and Tom DeFanti, is a low-cost, flash memory-based data server appliance that researchers can install in their labs to act as a Big Data hub, interfacing between their data-generating scientific instruments and the high-speed optical network, or to use as a Big Data analysis workstation driving interactive big data screens (from HD single screens to tiled display walls).

FIONA has enabled researchers, including Dr. Falko Kuester, who want to visualize big data from distributed locations using the latest virtual environment called Wide Angle Virtual Environment (WAVE), featured in a previously published success story. The WAVE requires billions of pixels to be rendered every second to create a realistic 3D virtual environment. When it was first designed, the WAVE drew data from file servers via the 10 gigabits per second (Gbps) campus network. However, the image rendering and updates were still not smooth enough and appeared "jerky" at times.

DeFanti, co-PI with Kuester on the WAVE project, and Papadopoulos, PI of the Prism@UCSD project, came up with an idea to build an inexpensive, low-power, low-noise appliance that includes a lot of flash drives, local disk drives, and powerful graphic processing units (GPUs). These appliances can then plug into 40Gbps networks and drive the display walls directly. FIONA was created as a box that can drive the displays, fetch data over the network, and cache necessary data locally. With RCI's help in optimizing the networking connection and system configuration, FIONA takes care of moving the data and local caching, and it works seamlessly with rendering algorithms for visualization on the WAVE, making virtual-reality research simpler, better and faster.

"With the help from RCI, we can put FIONA boxes on the Prism@UCSD network at 40 Gbps" — Dr. Tom DeFanti

The Prism@UCSD network is a "big data freeway" funded by the National Science Foundation (NSF). RCI provides fiber for the Prism@UCSD network at 40 Gbps.

FIONA is just one type of endpoint on the network, and WAVE is another. Other types include big computing and storage clusters at the San Diego Supercomputer Center (SDSC) and elsewhere on campus.

"RCI is simply a story of collaboration. FIONA will be a production service for all the researchers on campus" — Dr. Tom DeFanti

"There are a lot of people who work on the big data research: the staff, the scientists, everyone wants to work together," said DeFanti. "RCI allows us to collaborate."

Available to UCSD Researchers

While FIONA is technically for everyone, in addition to the appropriate hardware, it also requires competent system operators to configure and manage properly. It is currently an experimental service, but DeFanti and Papadopoulos foresee UC San Diego researchers adopting FIONAs in production in the near future. Ideally, researchers would just acquire the FIONA box like any PC and then their research can benefit from the high-performance network more easily.

100Gpbs Access Next Year

UC San Diego is among the few universities in the country to have a 40 Gbps network backbone, and it’s not stopping there. In 2015 the plan is to have a 100 Gbps connection completed under the Configurable, High-speed, Extensible Research Bandwidth (CHERuB) project, with SDSC Director Michael Norman as PI. DeFanti is confident that the campus big-data experience will be much improved with the continuation of RCI efforts, and FIONA will become one important and ubiquitous device to be found in practically every research lab on campus.

The work on FIONA is funded in part by the NSF Center for Integrated Access Networks (CIAN) under PI and Deputy Director Shaya Fainman) and the NSF IRNC award (with Tom DeFanti as PI).
